Iris Recognition SDK

Name: Iris Recognition SDK
Brand: Shenzhen Jupin Technology Co., Ltd.
SKU: JP-iM26T
Availability: InStock

Model Number:	JP-iM26T
MOQ:	Negotiable
Price:	Negotiable
Delivery Time:	5-8 work days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model:

JP-iM26T

Size:

75mm*20mm*15mm

Iris Image Format:

BMP Format

Iris Image Size:

Monocular Iris Image: 640 Pixels (width) × 480 Pixels (height)

Iris Image Quality:

Device Resolution: Within The Effective Capture Distance Range (35cm–45cm), The Device Resolution Shall Be No Less Than 4 Lp/mm (line Pairs Per Millimeter). Iris Image Sampling Resolution: No Less Than 16 Pixel/mm. Iris Image Grayscale Level: The Iris Im

Infrared Auxiliary Illumination:

810nm LED, <1mW/cm²

Image Sensor:

8 Megapixels

Auto Focus (AF):

Supported

Working Distance:

30cm – 60cm

Matching Modes:

1:1 And 1:N

Iris Recognition Accuracy:

FAR <0.001%, FRR <1%

Average Acquisition Time:

≤1s

Operation Mode & Interface:

The Module Integrates Built-in Eye Detection And Image Cropping (segmentation) Algorithms, And Connects To A PC Or Tablet Via UVC Interface For Iris Recognition.

Power Supply:

DC 5V

Power Consumption:

<2W

Operating Temperature:

-10°C To 50°C

Operating Humidity:

10% – 90% RH

Supply Ability:

200+/day

Highlight:

650nm IR Face Recognition Camera Module

COMS Face Recognition Camera Module

650nm IR face recognition module

Product Description

H185 USB Plug-and-Play 5-Megapixel Wide Dynamic Camera Module Effective pixel resolution: 2592*1944

H185 Wide Dynamic Camera Module Features:

USB 5M Wide Dynamic Camera
Suitable for facial feature detection
Plug-and-play
Effective pixel resolution: 2592*1944
Frame rate up to 30 FPS, ensuring image clarity and detail with CE ability
Large aperture/long depth of field, focal length is optional
Automatic exposure
Image stabilization
Backlight compensation
USB data interface connection

H185 Wide Dynamic Camera Module Parameter:

Connect the interface:	1* USB- 5pin-1.0mm
Interface speed:	480mb/s
Maximum resolution and frame rate:	2592*1944(30ps)
Other optional resolution ratio:	640* 480 (30fps), 800* 600(30fps), 1280* 720(30fps), 1024* 768(30fps), 1920* 1080(30fps), 1600* 1200(30ps), 2048* 1536(30fps), 2560* 1440(30ps)
Support format:	YUV/ MJPG
Max Dynamic range:	110 dB
F/No:	2.0
EFL:	3.5mm
FOV:	90°
Lens Construction:	2G4P+IR
Power Consumption:	Regular work: 0.7W
Operating systemrequest:	WinXP, Win7, Linux or Vista and android4.1

Iris Recognition SDK 0 Iris Recognition SDK 1
