7" Wall Mount QR Code & Contactless Card Access Control Terminal

Name: 7" Wall Mount QR Code & Contactless Card Access Control Terminal
Brand: Shenzhen Jupin Technology Co., Ltd.
SKU: JP171A
Price: Negotiable USD
Availability: InStock

Brand Name:	Shi Zun
Model Number:	JP171A
MOQ:	Negotiable
Price:	Negotiable
Delivery Time:	10 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Operating System:

Android 9.0

CPU:

Amlogic S905D3 1.8Ghz 4-core

NPU:

Supports 1.2T Arithmetic Power

Configure:

ROM-8GB

LCD Size:

7 Inch

Screen Resolution:

800*1280

Touchscreens:

10-point Capacitive Touch

Luminance:

300cd

Ethernet Port:

1 X 10/100 Adaptive Ethernet

Bluetooth:

V4.0

Horn (automobile Etc):

8 Ohm 3 Watt

Real Time Clock (RTC):

Be In Favor Of

Operating Temperature:

-20°C+60°C

QR Code Reader:

Support PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, Micro QR, Aztec, Hanxin And Other QR Codes.

QR Code Speed:

120 Frames Per Second

Reader:

Supports Mifare One (M1), S50, S70, UL:NTAG2xx Series Read/write. Protocol: ISO14443A, ISO14443B.

External Interface:

1 USB (OTG), 1 RJ45, 3 Relay Outputs, 2 Inputs (24V Input Supported), 1 DC.

Surface Materials And Processes:

Reinforced Glass

Body Material And Technology:

Aluminum CNC Engraving, Anodized Surface

Back Cover Material And Technology:

Aluminum CNC Engraving, Anodized Surface

Installation:

Hanging

Packaging Details:

7 inch

Supply Ability:

100+pcs+day

Product Description

7" Wall Mount QR Code & Contactless Card Access Control Terminal
