| Brand Name: | Shi Zun |
| Model Number: | K0 Board |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | T/T |
K0 Smart Vending Machine Board Rockchip RK3288 Wi-Fi 802.11 b/g/n and Bluetooth 4.0
K0 Smart Vending Machine Board Description:
The K0 board is powered by Allwinner A40i quad-core Cortex-A7 processor, with a maximum clock speed of 1.2GHz. The ARM dual-core Mali-400MP2 GPU supports OpenGL ES 2.0 / OpenVG 1.1, enabling a smooth hardware decoding and encoding of 1080p resolution videos. With a variety of on-board display interfaces, multiple I/O and expansion options, as well as a rich set of development kits, this board can be quickly applied to the vending machine sector.
Smart Vending Machine Board Parameters:
|
Keyword: |
Smart Vending Machine Board |
CPU: |
Allwinner A40i quad-core Cortex-A7@1.2GHz |
|---|---|---|---|
|
System Memory: |
1GB LPDDR3 |
Storage: |
8GB eMMC (128GB Max) |
|
USB Host: |
USB 2.0 ports (2 Ext. + 4 Int.) |
HDMI: |
HDMI 1.4, up to 1080p resolution |
| LVDS: | Dual-LVDS interface, up to 1080p resolution | MIPI: | 31-pin FPC MIPI-DSI interface/ 1920x1200 resolution |
| Power Amplifier: | 8 ohms, 6W dual audio power amplifier output | RTC: | Low power RTC with a CR1220 battery |
| Backlight: | Backlight control interface that turns the backlight on/off and adjusts the brightness level | GPIO: | 8x GPIO ports |
|
Android: |
7.1 (recommended) |
Serial Port: |
1xTTL/RS-485,6x TTL/RS-232 |
|
|
