| Model Number: | D-3568 Mainboard |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T |
D-3568 Edge Intelligent Computing Motherboard
Powered by the Rockchip RK3568 quad-core Cortex-A55 processor running at up to 2.0GHz, the D-3568 Edge Intelligent Computing Motherboard delivers next-generation performance for demanding edge applications. Built on a high-performance big.LITTLE architecture, this board combines exceptional computing power with advanced 2D/3D graphics and full HD video codec capabilities. What truly sets the D-3568 apart is its unparalleled display and connectivity versatility — featuring LVDS, MIPI-DSI, HDMI 2.0a (4K output), HDMI 1.4 input, and eDP interfaces, plus 2× Gigabit Ethernet, 9× serial ports (configurable as TTL/RS-232/RS-485), CAN Bus, I2C, and Wi-Fi 6 support. With a wide -20°C to 70°C operating temperature range and 9V–15V wide voltage input, the D-3568 is engineered for reliable operation in demanding environments. Ships with Android 11, Linux Buildroot, Debian 10, or Ubuntu 18.04, with open API SDK available for custom development — making it the ideal platform for vending machines, smart retail, and industrial automation.
Unmatched Display Versatility: The D-3568 stands alone in the lineup with 5 display interfaces — LVDS, MIPI-DSI, HDMI 2.0a (4K output), HDMI 1.4 input, and eDP. Whether driving large retail screens, embedded touch panels, or video capture displays, this board handles it all.
Wi-Fi 6 for Next-Gen Connectivity: Built-in Wi-Fi 6 (802.11 a/b/g/n/ac/ax) delivers faster speeds, lower latency, and better performance in crowded environments — essential for high-traffic retail and vending applications where connectivity reliability is critical.
9× Configurable Serial Ports: With 1× TTL, 2× TTL/RS-485 compatible, and 6× TTL/RS-232 compatible ports, the D-3568 offers the most flexible serial connectivity in the lineup — easily adapt to different peripherals without hardware changes.
Dual Gigabit Ethernet & CAN Bus: 2× Gigabit Ethernet ports provide redundant network connectivity for mission-critical applications, while 3× CAN Bus interfaces enable seamless integration with industrial automation and automotive-grade peripherals.
Built-in Amplifier & Professional Audio: Unlike other boards that only offer line-level output, the D-3568 features an 8Ω 6W dual audio amplifier for direct speaker connection — eliminating the need for external amplifier boards in vending machines and kiosks.
Comprehensive Display Control: Dedicated backlight control interfaces with on/off and brightness adjustment support — essential for vending machines and self-service kiosks that require display dimming for energy savings and nighttime operation.
The Ultimate Vending Machine Platform: From the touchscreen display to the payment system, from the product dispensing mechanism to the inventory sensors — the D-3568 has every interface you need for a complete vending machine solution. HDMI input for security camera integration, amplifier output for audio feedback, CAN Bus for expansion modules, and RS-485 for long-distance sensor communication.
Most Display Interfaces in the Lineup: With LVDS, MIPI-DSI, HDMI 2.0a output, HDMI 1.4 input, and eDP, the D-3568 offers unmatched display flexibility. Connect large retail displays, internal touch panels, secondary operator screens, and even video capture from security cameras — all on one board.
Wi-Fi 6 Future-Proofing: The D-3568 is the only board in the lineup with Wi-Fi 6 support — faster speeds, lower latency, and better performance in crowded retail environments. Future-proof your product with the latest wireless standard.
Built-In Audio Amplifier: 8Ω 6W dual speaker output means no extra amplifier board needed. Perfect for vending machines that play promotional audio, payment confirmation sounds, or interactive voice guidance — saves BOM cost and board space.
Industrial Temperature Range with Pro-Grade Reliability: -20°C to 70°C operating temperature and 2× Gigabit Ethernet for network redundancy ensure the D-3568 keeps running in challenging environments — from outdoor vending machines to cold chain logistics.
| Item | Details |
|---|---|
| Packaging | Anti-static bag + foam padding + industrial carton |
| MOQ | 1 piece (sample order), 100+ for volume pricing |
| Lead Time | 3–5 working days for samples; 15–20 working days for bulk orders |
| Shipping | DHL, FedEx, UPS, or by sea (customer's choice) |
| C0 Smart Mini | C3 Smart Mini | C4 Smart Computing | C300 Industrial Box | D-3568 Edge Intelligent | |
|---|---|---|---|---|---|
| Best For | Industrial control, basic signage | Premium signage, HMI | AI, edge computing | Gaming, fitness, kiosks | Vending machines, smart retail, industrial automation |
| CPU | A40i @ 1.2GHz | RK3288 @ 1.6GHz | RK3399 @ 1.8GHz | RK3288 @ 1.8GHz | RK3568 @ 2.0GHz |
| Wi-Fi | 802.11 b/g/n | 802.11 b/g/n | 802.11 b/g/n | 802.11 b/g/n | Wi-Fi 6 (a/b/g/n/ac/ax) |
| Ethernet | 1× 10/100M | 1× 10/100M | 1× 10/100/1000M | 1× 10/100M | 2× 10/100/1000M |
| Serial Ports | 6× TTL/RS-232 | 4× TTL/RS-232 | 2× TTL/RS-232 | 4× RS232 | 9× (TTL/RS-232/RS-485 configurable) |
| Display Interfaces | HDMI + VGA | HDMI 2.0 + VGA | HDMI 2.0 + VGA | HDMI 2.0 + VGA | LVDS + MIPI-DSI + HDMI 2.0a + HDMI Input + eDP |
| Audio | Line + MIC | Line + MIC | Line + MIC | Line + MIC | Line + AMP (8Ω 6W) + MIC + Line Input |
| Special Features | Most serial ports (C0) | Best 4K value | USB 3.0, Type-C, GbE | Ready-to-deploy box | HDMI input, CAN Bus, I2C, backlight control, Wi-Fi 6 |
| Operating Temp | 0°C ~ 70°C | 0°C ~ 70°C | 0°C ~ 70°C | -20°C ~ 70°C | -20°C ~ 70°C |
| OS Options | Android 7.1 | Android 5.1/6.0/7.1 | Android 7.1/8.1 | Android 5.1/6.0/7.1, Linux | Android 11, Buildroot, Debian 10, Ubuntu 18.04 |
| Key Differentiator | Legacy-friendly, cost-effective | Premium visuals | AI-ready, high-speed data | Ready-to-deploy enclosure | Most versatile, vending-focused, Wi-Fi 6, HDMI input, CAN Bus |
|
|
