| Model Number: | JP2102A |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T |
Product Overview:
This 10.1-inch horizontal screen wall-mounted facial recognition access control and attendance machine is an intelligent access control device that integrates facial recognition technology. It is equipped with the Android operating system and provides an open platform, supporting secondary development to meet the needs of different users.
Technical Features:
1. Operating System: Utilizes Android 11 operating system, providing a stable operating environment and a rich application ecosystem.
2. High-definition Display: Equipped with a 10.1-inch IPS full-view high-definition touch screen with a resolution of 1280*800, offering clear image display.
3. Camera: Uses a 2-megapixel wide dynamic camera, supporting face recognition in low-light or no-light environments.
6. Live Detection: Supports live detection function, effectively preventing various types of attacks such as PS face swapping, video, and high-definition portrait photos.
7. Quick Recognition: Based on deep learning algorithms, face recognition speed is less than 0.2 seconds, with an accuracy rate of ≥ 99%.
8. Network Connection: Supports wired network and optional WiFi or 4G connection, facilitating device network management.
Application Advantages:
Security: Combining facial recognition technology, it provides a higher level of security protection.
Convenience: Users do not need to carry an access card and can pass through quickly by facial recognition or fingerprint.
Flexibility: Supports multiple authentication methods, adapting to the needs of different users.
Application Scenarios:
Suitable for various scenarios such as office buildings, schools, parks, communities, factories, public venues, etc.
This 10.1-inch horizontal screen wall-mounted facial recognition access control and attendance machine, with its efficient recognition speed, wide application scenarios, high security, and precise recognition accuracy, provides users with a convenient and secure identity verification solution.
| 10.1-Inch Smart Electronic Doorplate Device Parameters | ||
|
Basic Parameters |
Operating System | Android 8.0 system |
| Performance | RK3288 main frequency up to 1.8 GHZ | |
| Configuration | 2GB RAM + 16GB storage memory | |
| LCD Screen Size | 10.1 inches | |
| Screen Resolution | 1280*800 | |
| Brightness | 500cd/m², super long life, stable performance, service life of up to 60,000 hours, able to work 24/7 all year round | |
| Touchscreen | 10-point G+G capacitive touch screen, any point can withstand more than 50 million touches | |
| Camera | 2 million pixels, ultra-wide dynamic range, anti-backlight and strong light, selectable shooting focal length | |
| Speaker | Built-in 8Ω/3W | |
| 485 Output | Support | |
| Relay Door Opening | Support | |
| Ethernet | 1 10/100/1000Mbps adaptive Ethernet | |
| PoE Power Supply | Support | |
| Three-Color Indicator Light | Red, blue, green | |
| External Interfaces | 2 USB ports, 1 RJ45 port, 1 DC port, 1 TF card slot, 1 SIM card slot, 1 HDMI, and external 485/232/relay | |
| Face Algorithm |
Dynamic face detection and tracking based on video stream, 1:N recognition algorithm; Supports 50,000 face photo libraries and 1 million recognition records; When the face database is 50,000, the false recognition rate is 0.01% and the pass rate is 97%; |
|
| Working Parameters | Voltage 12V, current 3A, operating temperature-25℃～+75℃, humidity 5%~93%RH non-condensing | |
| Materials | Surface Material | Mohs Level 7 Tempered glass, explosion-proof and collision-proof, anti-scratch |
| Body Craftsmanship | Aluminum alloy CNC precision-machined and anodized frame + sheet metal back cover with powder coating finish | |
| Color | Black + Silver | |
| Standard Features | Turnstile-Electromagnetic Lock Linkage | Connect to the gate barrier and electromagnetic lock, and set it up to open the door after a successful facial comparison |
| Network Upload | Cooperating with the server software, it can realize the upload and summary of comparison information of multiple terminals | |
| Installation | Wall-Mounted | |
|
| Model Number: | JP2102A |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 10.1 inches |
| Payment Terms: | T/T |
Product Overview:
This 10.1-inch horizontal screen wall-mounted facial recognition access control and attendance machine is an intelligent access control device that integrates facial recognition technology. It is equipped with the Android operating system and provides an open platform, supporting secondary development to meet the needs of different users.
Technical Features:
1. Operating System: Utilizes Android 11 operating system, providing a stable operating environment and a rich application ecosystem.
2. High-definition Display: Equipped with a 10.1-inch IPS full-view high-definition touch screen with a resolution of 1280*800, offering clear image display.
3. Camera: Uses a 2-megapixel wide dynamic camera, supporting face recognition in low-light or no-light environments.
6. Live Detection: Supports live detection function, effectively preventing various types of attacks such as PS face swapping, video, and high-definition portrait photos.
7. Quick Recognition: Based on deep learning algorithms, face recognition speed is less than 0.2 seconds, with an accuracy rate of ≥ 99%.
8. Network Connection: Supports wired network and optional WiFi or 4G connection, facilitating device network management.
Application Advantages:
Security: Combining facial recognition technology, it provides a higher level of security protection.
Convenience: Users do not need to carry an access card and can pass through quickly by facial recognition or fingerprint.
Flexibility: Supports multiple authentication methods, adapting to the needs of different users.
Application Scenarios:
Suitable for various scenarios such as office buildings, schools, parks, communities, factories, public venues, etc.
This 10.1-inch horizontal screen wall-mounted facial recognition access control and attendance machine, with its efficient recognition speed, wide application scenarios, high security, and precise recognition accuracy, provides users with a convenient and secure identity verification solution.
| 10.1-Inch Smart Electronic Doorplate Device Parameters | ||
|
Basic Parameters |
Operating System | Android 8.0 system |
| Performance | RK3288 main frequency up to 1.8 GHZ | |
| Configuration | 2GB RAM + 16GB storage memory | |
| LCD Screen Size | 10.1 inches | |
| Screen Resolution | 1280*800 | |
| Brightness | 500cd/m², super long life, stable performance, service life of up to 60,000 hours, able to work 24/7 all year round | |
| Touchscreen | 10-point G+G capacitive touch screen, any point can withstand more than 50 million touches | |
| Camera | 2 million pixels, ultra-wide dynamic range, anti-backlight and strong light, selectable shooting focal length | |
| Speaker | Built-in 8Ω/3W | |
| 485 Output | Support | |
| Relay Door Opening | Support | |
| Ethernet | 1 10/100/1000Mbps adaptive Ethernet | |
| PoE Power Supply | Support | |
| Three-Color Indicator Light | Red, blue, green | |
| External Interfaces | 2 USB ports, 1 RJ45 port, 1 DC port, 1 TF card slot, 1 SIM card slot, 1 HDMI, and external 485/232/relay | |
| Face Algorithm |
Dynamic face detection and tracking based on video stream, 1:N recognition algorithm; Supports 50,000 face photo libraries and 1 million recognition records; When the face database is 50,000, the false recognition rate is 0.01% and the pass rate is 97%; |
|
| Working Parameters | Voltage 12V, current 3A, operating temperature-25℃～+75℃, humidity 5%~93%RH non-condensing | |
| Materials | Surface Material | Mohs Level 7 Tempered glass, explosion-proof and collision-proof, anti-scratch |
| Body Craftsmanship | Aluminum alloy CNC precision-machined and anodized frame + sheet metal back cover with powder coating finish | |
| Color | Black + Silver | |
| Standard Features | Turnstile-Electromagnetic Lock Linkage | Connect to the gate barrier and electromagnetic lock, and set it up to open the door after a successful facial comparison |
| Network Upload | Cooperating with the server software, it can realize the upload and summary of comparison information of multiple terminals | |
| Installation | Wall-Mounted | |
