| Model Number: | JP1812A |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T |
Product Overview:
This 8-inch Linux system facial recognition access control machine is an intelligent terminal device that integrates facial recognition, access control, and attendance management functions. It employs advanced facial recognition technology and offers an efficient and secure identity verification solution, suitable for various scenarios such as office buildings, residential communities, and schools.
Technical Features:
1. High-definition display: Equipped with an 8-inch LCD screen with a 16:9 aspect ratio and a resolution of 800×1280, providing clear image display.
2. Dual cameras: Utilizes a 2-megapixel dual camera, with a facial recognition distance of 0.3-2 meters, supporting dual live body detection technology, effectively preventing attacks such as photos, videos, and models.
3. Deep learning algorithm: The device adopts a deep learning algorithm, supporting up to 50,000 or 100,000 face database management, with a 1:N face recognition time of less than 500ms.
4. Multi-touch control: The 8-inch LED color screen supports ten-point touch control, providing a smooth interaction experience.
5. Dust and water resistance design: Industrial-level dust and water resistance, suitable for various environments.
6. Multiple authentication methods: Supports face recognition, card swiping, employee ID, password, and other verification methods.
7. Quick identification: Face comparison time ≤ 0.3 seconds, face verification accuracy rate ≥ 99%
8. Large-capacity event storage: Supports 20,000 event storage.
9. Network connection: Supports TCP/IP transmission mode.
| 8-Inch High-End Face Recognition Access Control All-in-One Machine Oval Shape Parameters | ||
|
Basic Parameters |
Operating System | Android 11 system, also supports Ubuntu20.04, Debian10, Linux, Buildroot and Hongmeng system |
| Performance | RK3568, a quad-core Cortex-A55 architecture processor with a main frequency of up to 2.0MHz, a built-in convolutional neural network accelerator NPU, and supports 1T computing power | |
| Configuration | 2GB RAM + 16GB storage memory, LPDDR4 optional 4GB/8GB, EMMC supports up to 128GB | |
| LCD Screen Size | 8 inches | |
| Screen Resolution | 800*1280 | |
| Viewing Angle | IPS full viewing angle | |
| Brightness | 500cd/m², stable performance, service life of up to more than 60,000 hours, able to work 24/7 all year round | |
| Touchscreen | 10-point G+G capacitive touch screen, any point can withstand more than 50 million touches | |
| Camera | 2 million pixels, ultra-wide dynamic range, anti-backlight and strong light, selectable shooting focal length | |
| WIFI | High-performance WIFI, supports 802.11B/G/N | |
| Bluetooth | High-performance Bluetooth, supporting BT V5.2 | |
| Ethernet | 1 10/100/1000Mbps adaptive Ethernet | |
| Three-Color Indicator Light | Red, blue, green | |
| Card Reader | Optional IC/ID/NFC/ID card reader, reading time <1S, card reading distance: 5-30MM | |
| Microphone | Optional | |
| 4G | Optional | |
| PoE | Optional | |
| Speaker | Built-in 8Ω/3W | |
| Working Parameters | Voltage 12V; Current 3A; Operating temperature-25℃～+75℃; Humidity 5%~93%RH non-condensing | |
| External Interfaces | 1 USB/OTG, 1 RJ45 standard interface, 1 relay output, 1 DC power supply, 1 Wiegand, 1 232/485 | |
| Face Algorithm |
Dynamic face detection and tracking based on video stream, 1:N recognition algorithm; Supports 50,000 face photo libraries and 1 million recognition records; When the face database is 50,000, the false recognition rate is 0.01% and the pass rate is 97%; |
|
|
Materials |
Surface Material | Mohs Level 7 Tempered glass explosion-proof and collision-proof, anti-scratch |
| Body Craftsmanship | CNC-machined aluminum alloy with anodized finish | |
| Color | Black + Gray | |
| Standard Features | Turnstile-Electromagnetic Lock Linkage | Connect to the gate barrier and electromagnetic lock, and set it up to open the door after a successful verification |
| Network Upload | Cooperating with the server software, it can realize the upload and summary of comparison information of multiple terminals | |
| Installation | Pole-Mounted | |
|
| Model Number: | JP1812A |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 8 inches |
| Payment Terms: | T/T |
Product Overview:
This 8-inch Linux system facial recognition access control machine is an intelligent terminal device that integrates facial recognition, access control, and attendance management functions. It employs advanced facial recognition technology and offers an efficient and secure identity verification solution, suitable for various scenarios such as office buildings, residential communities, and schools.
Technical Features:
1. High-definition display: Equipped with an 8-inch LCD screen with a 16:9 aspect ratio and a resolution of 800×1280, providing clear image display.
2. Dual cameras: Utilizes a 2-megapixel dual camera, with a facial recognition distance of 0.3-2 meters, supporting dual live body detection technology, effectively preventing attacks such as photos, videos, and models.
3. Deep learning algorithm: The device adopts a deep learning algorithm, supporting up to 50,000 or 100,000 face database management, with a 1:N face recognition time of less than 500ms.
4. Multi-touch control: The 8-inch LED color screen supports ten-point touch control, providing a smooth interaction experience.
5. Dust and water resistance design: Industrial-level dust and water resistance, suitable for various environments.
6. Multiple authentication methods: Supports face recognition, card swiping, employee ID, password, and other verification methods.
7. Quick identification: Face comparison time ≤ 0.3 seconds, face verification accuracy rate ≥ 99%
8. Large-capacity event storage: Supports 20,000 event storage.
9. Network connection: Supports TCP/IP transmission mode.
| 8-Inch High-End Face Recognition Access Control All-in-One Machine Oval Shape Parameters | ||
|
Basic Parameters |
Operating System | Android 11 system, also supports Ubuntu20.04, Debian10, Linux, Buildroot and Hongmeng system |
| Performance | RK3568, a quad-core Cortex-A55 architecture processor with a main frequency of up to 2.0MHz, a built-in convolutional neural network accelerator NPU, and supports 1T computing power | |
| Configuration | 2GB RAM + 16GB storage memory, LPDDR4 optional 4GB/8GB, EMMC supports up to 128GB | |
| LCD Screen Size | 8 inches | |
| Screen Resolution | 800*1280 | |
| Viewing Angle | IPS full viewing angle | |
| Brightness | 500cd/m², stable performance, service life of up to more than 60,000 hours, able to work 24/7 all year round | |
| Touchscreen | 10-point G+G capacitive touch screen, any point can withstand more than 50 million touches | |
| Camera | 2 million pixels, ultra-wide dynamic range, anti-backlight and strong light, selectable shooting focal length | |
| WIFI | High-performance WIFI, supports 802.11B/G/N | |
| Bluetooth | High-performance Bluetooth, supporting BT V5.2 | |
| Ethernet | 1 10/100/1000Mbps adaptive Ethernet | |
| Three-Color Indicator Light | Red, blue, green | |
| Card Reader | Optional IC/ID/NFC/ID card reader, reading time <1S, card reading distance: 5-30MM | |
| Microphone | Optional | |
| 4G | Optional | |
| PoE | Optional | |
| Speaker | Built-in 8Ω/3W | |
| Working Parameters | Voltage 12V; Current 3A; Operating temperature-25℃～+75℃; Humidity 5%~93%RH non-condensing | |
| External Interfaces | 1 USB/OTG, 1 RJ45 standard interface, 1 relay output, 1 DC power supply, 1 Wiegand, 1 232/485 | |
| Face Algorithm |
Dynamic face detection and tracking based on video stream, 1:N recognition algorithm; Supports 50,000 face photo libraries and 1 million recognition records; When the face database is 50,000, the false recognition rate is 0.01% and the pass rate is 97%; |
|
|
Materials |
Surface Material | Mohs Level 7 Tempered glass explosion-proof and collision-proof, anti-scratch |
| Body Craftsmanship | CNC-machined aluminum alloy with anodized finish | |
| Color | Black + Gray | |
| Standard Features | Turnstile-Electromagnetic Lock Linkage | Connect to the gate barrier and electromagnetic lock, and set it up to open the door after a successful verification |
| Network Upload | Cooperating with the server software, it can realize the upload and summary of comparison information of multiple terminals | |
| Installation | Pole-Mounted | |
