| Model Number: | 007 |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T |
Introduction: This product is mainly used in factories, enterprises, institutions, etc. for facial attendance checking and access control. It can be used independently or connected to a network.
Characteristics:
1. The aircraft-grade aluminum integrated fuselage offers high protection, high strength, and long-lasting durability.
2. Quick installation: Plug and play, easy to use, wireless or wired connection is available.
3. Large identification library capacity: Supports a local personnel database of 50,000 people.
4. Standardized interfaces: The equipment supports the Venetian Wire Protocol for the access control industry, and the equipment supports API interface integration with third-party systems.
5. Automatic exposure adjustment: Can adapt to strong light, dim light, and backlighting, and can accurately identify in various extreme lighting environments.
6. There are three color indicator lights: white, green, and blue.
| Specifications of the 8-inch Smart Facial Recognition Access Control Terminal | ||
| essential parameter | operating system | Android 11 also supports Ubuntu 20.04, Debian 10, Linux, Buildroot, and HarmonyOS. |
| function | K3568: a quad-core Cortex-A55 architecture processor with a clock speed of up to 2.0 MHz, featuring a built-in Convolutional Neural Network Accelerator (NPU), and supporting 1 T of computing power. | |
| configure | 2 GB of RAM + 16 GB of storage; LPDDR4 memory available in 4 GB/8 GB variants; EMMC support up to 128 GB. | |
| LCD screen size | 8 inches | |
| screen resolution | 800*1280 | |
| Viewing angle | IPS Full-View | |
| luminance | 500 cd/m², ultra-long service life, stable performance, with a service life exceeding 60,000 hours, enabling uninterrupted 24/7 operation throughout the year. | |
| touch screen | 10-point G+G capacitive touch screen, capable of withstanding over 50 million touches at any single point. | |
| camera | Dual-camera setup featuring visible light and infrared sensors with 2 million pixels, ultra-wide dynamic range, live detection support, resistance to backlit and high-intensity lighting, and selectable focal lengths. | |
| WIFI | High-performance Wi-Fi, supports 802.11b/g/n | |
| PDA | High-performance Bluetooth, supports Bluetooth Version 5.2 | |
| Ethernet | Route 1: 10/100/1000 Mbps adaptive Ethernet | |
| Indication light | Red, white, and green LED lights | |
| card reader | Optional IC/ID/NFC/ID card reader; read time <1s; card reading range: 5–30 mm | |
| microphone | Optional | |
| 4G | Optional | |
| POE | Optional | |
| Speaker | Built-in 8Ω/3W | |
| operational parameter | Voltage: 12 V; Current: 3 A; Operating temperature: –25 °C to +75 °C; Relative humidity: 5%–93% RH (non-condensing) | |
| outer joint | 1 x USB/OTG port, 1 x RJ45 standard interface, 1 x relay output, 1 x DC power supply, 1 x Vengen port, 1 x RS-232/RS-485 port | |
| Face recognition algorithm | Dynamic face detection and tracking based on video streams; 1:N recognition algorithm; dynamic dual-camera anti-counterfeiting capability, effectively eliminating fraud in photos and videos across various media formats; supports a face database of 50,000 images and 1 million recognition records; when the face database contains 50,000 images, the false recognition rate is 0.01%, and the recognition pass rate is 97%. | |
| material quality | Surface material | Mo-type Grade 7 tempered glass: explosion-proof, impact-resistant, and scratch-resistant |
| Process Engineering | CNC precision engraving and anodizing of aluminum alloy | |
| pigment | Black + Silver | |
| Standard Features | Turnstile with electromagnetic lock linkage | Integrate the access gate and the electromagnetic lock to open the gate upon successful facial recognition verification. |
| Upload via network | In conjunction with the server-side software, it enables the uploading and aggregation of comparison data from multiple terminals. | |
| way to install | Barrier gate installation | |
|
|
| Model Number: | 007 |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 8 inches |
| Payment Terms: | T/T |
Introduction: This product is mainly used in factories, enterprises, institutions, etc. for facial attendance checking and access control. It can be used independently or connected to a network.
Characteristics:
1. The aircraft-grade aluminum integrated fuselage offers high protection, high strength, and long-lasting durability.
2. Quick installation: Plug and play, easy to use, wireless or wired connection is available.
3. Large identification library capacity: Supports a local personnel database of 50,000 people.
4. Standardized interfaces: The equipment supports the Venetian Wire Protocol for the access control industry, and the equipment supports API interface integration with third-party systems.
5. Automatic exposure adjustment: Can adapt to strong light, dim light, and backlighting, and can accurately identify in various extreme lighting environments.
6. There are three color indicator lights: white, green, and blue.
| Specifications of the 8-inch Smart Facial Recognition Access Control Terminal | ||
| essential parameter | operating system | Android 11 also supports Ubuntu 20.04, Debian 10, Linux, Buildroot, and HarmonyOS. |
| function | K3568: a quad-core Cortex-A55 architecture processor with a clock speed of up to 2.0 MHz, featuring a built-in Convolutional Neural Network Accelerator (NPU), and supporting 1 T of computing power. | |
| configure | 2 GB of RAM + 16 GB of storage; LPDDR4 memory available in 4 GB/8 GB variants; EMMC support up to 128 GB. | |
| LCD screen size | 8 inches | |
| screen resolution | 800*1280 | |
| Viewing angle | IPS Full-View | |
| luminance | 500 cd/m², ultra-long service life, stable performance, with a service life exceeding 60,000 hours, enabling uninterrupted 24/7 operation throughout the year. | |
| touch screen | 10-point G+G capacitive touch screen, capable of withstanding over 50 million touches at any single point. | |
| camera | Dual-camera setup featuring visible light and infrared sensors with 2 million pixels, ultra-wide dynamic range, live detection support, resistance to backlit and high-intensity lighting, and selectable focal lengths. | |
| WIFI | High-performance Wi-Fi, supports 802.11b/g/n | |
| PDA | High-performance Bluetooth, supports Bluetooth Version 5.2 | |
| Ethernet | Route 1: 10/100/1000 Mbps adaptive Ethernet | |
| Indication light | Red, white, and green LED lights | |
| card reader | Optional IC/ID/NFC/ID card reader; read time <1s; card reading range: 5–30 mm | |
| microphone | Optional | |
| 4G | Optional | |
| POE | Optional | |
| Speaker | Built-in 8Ω/3W | |
| operational parameter | Voltage: 12 V; Current: 3 A; Operating temperature: –25 °C to +75 °C; Relative humidity: 5%–93% RH (non-condensing) | |
| outer joint | 1 x USB/OTG port, 1 x RJ45 standard interface, 1 x relay output, 1 x DC power supply, 1 x Vengen port, 1 x RS-232/RS-485 port | |
| Face recognition algorithm | Dynamic face detection and tracking based on video streams; 1:N recognition algorithm; dynamic dual-camera anti-counterfeiting capability, effectively eliminating fraud in photos and videos across various media formats; supports a face database of 50,000 images and 1 million recognition records; when the face database contains 50,000 images, the false recognition rate is 0.01%, and the recognition pass rate is 97%. | |
| material quality | Surface material | Mo-type Grade 7 tempered glass: explosion-proof, impact-resistant, and scratch-resistant |
| Process Engineering | CNC precision engraving and anodizing of aluminum alloy | |
| pigment | Black + Silver | |
| Standard Features | Turnstile with electromagnetic lock linkage | Integrate the access gate and the electromagnetic lock to open the gate upon successful facial recognition verification. |
| Upload via network | In conjunction with the server-side software, it enables the uploading and aggregation of comparison data from multiple terminals. | |
| way to install | Barrier gate installation | |
