| Model Number: | F1-i Mainboard |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T |
F1-i Smart Face Recognition Access Control Motherboard
Designed specifically for the security and access control industry, the F1-i Smart Face Recognition Access Control Motherboard is powered by the Rockchip PX30 quad-core Cortex-A35 processor running at up to 1.5GHz. The integrated Mali-Dvalin-2EE GPU supports OpenGL ES 3.2, Vulkan 1.0, and OpenCL 2.0, delivering 1080P hardware video encoding and decoding — essential for real-time face recognition and video capture applications. What truly sets the F1-i apart is its comprehensive access control-specific feature set: Wiegand input/output interface, SPDT door control relay (up to 2A), bell control relay, 4× LED driver interfaces, ambient light sensor, and dual 8Ω 10W amplifier outputs for clear audio feedback. The board also features a MIPI+DVP dual camera port supporting simultaneous dual-camera input — perfect for face recognition systems that require both RGB and IR cameras for liveness detection. With 9× configurable serial ports, 5× GPIO, I2C, and battery power support (8.4V 2-cell Li-ion with charging), the F1-i delivers all the specialized interfaces needed for intelligent door access systems, time attendance terminals, and security checkpoints. Ships with Android 8.1, with open API SDK available for custom development. Operating temperature range 0°C to 70°C.
Purpose-Built for Face Recognition: Unlike general-purpose boards, the F1-i is engineered specifically for face recognition access control. The MIPI+DVP dual camera port enables simultaneous RGB + IR camera input for liveness detection — preventing spoofing with photos or videos.
Comprehensive Door Control Interfaces: Features a complete access control suite — SPDT relay (up to 2A) for door locks, bell control relay, Wiegand input/output for connecting standard card readers, and 4× LED driver interfaces for multi-color status indicators.
Powerful Audio with 10W Amplifier: Dual 8Ω 10W amplifier outputs deliver clear, loud audio for voice prompts, access confirmation sounds, and alarm notifications — ensuring users hear feedback even in noisy environments.
Flexible Power Options: Supports both 9V–15V DC wide voltage input and 8.4V 2-cell Li-ion battery power with onboard charging — enabling battery backup for uninterrupted operation during power outages.
Dual Camera Support with Hardware Encoding: 1080P hardware video encoding and decoding, combined with the MIPI+DVP dual camera interface, enables real-time face capture, encoding, and comparison directly on the board — no external encoder needed.
Rich Accessory Control: Ambient light sensor for automatic screen brightness adjustment, 12V fan port for thermal management, and I2C interface for capacitive touch screens — all the peripherals needed for a complete access control terminal.
Purpose-Built, Not Repurposed: The F1-i isn't a general-purpose board adapted for access control — it's designed from the ground up with the specific interfaces access control systems need: Wiegand, door lock relays, bell control, LED indicators, and light sensors. No external adapter boards, no complex wiring — plug and play.
Liveness Detection Ready: The dual camera interface (MIPI + DVP) supports simultaneous RGB and IR cameras — enabling facial liveness detection to prevent spoofing. This is essential for modern access control systems that require biometric authentication.
10W Audio for Clear Communication: Unlike boards with only line-level output, the F1-i features 8Ω 10W dual amplifiers — drive speakers directly for loud, clear voice prompts. Perfect for noisy factory floors, outdoor entrances, and public buildings.
Built-In Battery Backup: The onboard 2-cell Li-ion battery support with charging circuitry ensures your access control system stays operational during power failures — critical for security applications where downtime is not an option.
Complete Door Control in One Board: SPDT relay (up to 2A) + Wiegand interface + bell control + 4 LED drivers + light sensor + thermal management — the F1-i has everything you need for a professional access control terminal, reducing BOM complexity and speeding up development.
| Item | Details |
|---|---|
| Packaging | Anti-static bag + foam padding + industrial carton |
| MOQ | 1 piece (sample order), 100+ for volume pricing |
| Lead Time | 3–5 working days for samples; 15–20 working days for bulk orders |
| Shipping | DHL, FedEx, UPS, or by sea (customer's choice) |
|
|
