| Model Number: | 018 |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T |
Product Overview:
This 21.5-inch horizontal screen wall-mounted touch all-in-one device is an intelligent device integrated with the Windows operating system, designed specifically for occasions requiring high-performance computing and multi-touch operation. With its large-sized horizontal screen design, high-definition display, and powerful processing capabilities, it offers users a convenient and intuitive interactive experience.
Technical Features:
1. High-definition Display: Equipped with a 21.5-inch full HD LED backlit display with a resolution of 1920×1080, providing a clear visual experience and smooth touch operation.
2. Multi-touch: Supports 10-point capacitive touch, offering sensitive touch response.
3. Powerful Processing Capability: Equipped with an industrial-grade motherboard solution.
4. Rich Interfaces: Provides multiple interface options, including USB 2.0, USB 3.0, HDMI, VGA, RJ45, etc., to meet various peripheral connection requirements.
5. Operating System: Pre-installed with the Windows operating system, users can choose Win 7, Win 10, etc. versions as per their needs.
6. Network Connectivity: Supports Ethernet LAN, Wi-Fi (expandable 4G wireless module, Bluetooth 4.0).
Application Advantages:
Enhanced Work Efficiency: Quick response speed and accurate touch operation effectively improve work efficiency.
Flexibility: Supports embedded, wall-mounted, and swivel-arm installation methods, adapting to different scene requirements.
Application Scenarios:
Commercial Display: Widely used in outdoor places such as scenic spots, parks, communities, streets, and media business districts to display commercial advertising information and multimedia audio-visual systems related to the application scenarios.
Educational Training: Suitable for educational institutions and training centers, providing interactive teaching experiences.
Enterprise Office: Used for enterprise meeting rooms, reception areas, etc., enhancing brand image and work efficiency.
| Specifications of the 21.5-inch embedded capacitive all-in-one touchscreen device | ||
| essential parameter | operating system | Win10 |
| function | Intel Core i5-4xxx, dual-core, 1.6 + 2.6 GHz | |
| configure | 8GB RAM, 128GB storage | |
| LCD screen size | 21.5 inches | |
| screen resolution | 1920*1080 | |
| Viewing angle | IPS Full-View | |
| luminance | 300 cd/m², ultra-long service life, stable performance, with a service life exceeding 60,000 hours, enabling uninterrupted operation 24/7 throughout the year. | |
| touch screen | 10-point G+G capacitive touch, with each point capable of withstanding over 50 million touches. | |
| WIFI | High-performance Wi-Fi, supports 802.11b/g/n | |
| PDA | High-performance Bluetooth, supports BT V5.2 | |
| Ethernet | Route 1: 10/100/1000 Mbps adaptive Ethernet | |
| 4G | Optional | |
| Speaker | Built-in 8Ω/3W*2 | |
| operational parameter | Voltage: 12 V; Current: 4 A; Operating temperature: –25 °C to +75 °C; Relative humidity: 5%–93% RH (non-condensable gases) | |
| outer joint | 1 DC port, 1 HDMI port, 1 VGA port, 1 RJ45 port, 2 x 2.0 USB ports, 2 x 3.0 USB ports, 1 MIC jack, 1 LIN jack | |
| material quality | Surface material | Mo-type Grade 7 tempered glass: explosion-proof, impact-resistant, and scratch-resistant |
| Process Technology | Aluminum alloy CNC precision-engraved anodized frame + sheet metal bending and powder coating process | |
| pigment | Black + Silver | |
| Standard Features | Turnstile with electromagnetic lock linkage | Integrate the access gate and the electromagnetic lock to open the gate upon successful facial recognition. |
| Upload via network | In conjunction with the server-side software, it enables the uploading and aggregation of comparison data from multiple terminals. | |
| way to install | In-socket installation | |
Video
|
|
| Model Number: | 018 |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 384.16×233.5×(13+29) mm. |
| Payment Terms: | T/T |
Product Overview:
This 21.5-inch horizontal screen wall-mounted touch all-in-one device is an intelligent device integrated with the Windows operating system, designed specifically for occasions requiring high-performance computing and multi-touch operation. With its large-sized horizontal screen design, high-definition display, and powerful processing capabilities, it offers users a convenient and intuitive interactive experience.
Technical Features:
1. High-definition Display: Equipped with a 21.5-inch full HD LED backlit display with a resolution of 1920×1080, providing a clear visual experience and smooth touch operation.
2. Multi-touch: Supports 10-point capacitive touch, offering sensitive touch response.
3. Powerful Processing Capability: Equipped with an industrial-grade motherboard solution.
4. Rich Interfaces: Provides multiple interface options, including USB 2.0, USB 3.0, HDMI, VGA, RJ45, etc., to meet various peripheral connection requirements.
5. Operating System: Pre-installed with the Windows operating system, users can choose Win 7, Win 10, etc. versions as per their needs.
6. Network Connectivity: Supports Ethernet LAN, Wi-Fi (expandable 4G wireless module, Bluetooth 4.0).
Application Advantages:
Enhanced Work Efficiency: Quick response speed and accurate touch operation effectively improve work efficiency.
Flexibility: Supports embedded, wall-mounted, and swivel-arm installation methods, adapting to different scene requirements.
Application Scenarios:
Commercial Display: Widely used in outdoor places such as scenic spots, parks, communities, streets, and media business districts to display commercial advertising information and multimedia audio-visual systems related to the application scenarios.
Educational Training: Suitable for educational institutions and training centers, providing interactive teaching experiences.
Enterprise Office: Used for enterprise meeting rooms, reception areas, etc., enhancing brand image and work efficiency.
| Specifications of the 21.5-inch embedded capacitive all-in-one touchscreen device | ||
| essential parameter | operating system | Win10 |
| function | Intel Core i5-4xxx, dual-core, 1.6 + 2.6 GHz | |
| configure | 8GB RAM, 128GB storage | |
| LCD screen size | 21.5 inches | |
| screen resolution | 1920*1080 | |
| Viewing angle | IPS Full-View | |
| luminance | 300 cd/m², ultra-long service life, stable performance, with a service life exceeding 60,000 hours, enabling uninterrupted operation 24/7 throughout the year. | |
| touch screen | 10-point G+G capacitive touch, with each point capable of withstanding over 50 million touches. | |
| WIFI | High-performance Wi-Fi, supports 802.11b/g/n | |
| PDA | High-performance Bluetooth, supports BT V5.2 | |
| Ethernet | Route 1: 10/100/1000 Mbps adaptive Ethernet | |
| 4G | Optional | |
| Speaker | Built-in 8Ω/3W*2 | |
| operational parameter | Voltage: 12 V; Current: 4 A; Operating temperature: –25 °C to +75 °C; Relative humidity: 5%–93% RH (non-condensable gases) | |
| outer joint | 1 DC port, 1 HDMI port, 1 VGA port, 1 RJ45 port, 2 x 2.0 USB ports, 2 x 3.0 USB ports, 1 MIC jack, 1 LIN jack | |
| material quality | Surface material | Mo-type Grade 7 tempered glass: explosion-proof, impact-resistant, and scratch-resistant |
| Process Technology | Aluminum alloy CNC precision-engraved anodized frame + sheet metal bending and powder coating process | |
| pigment | Black + Silver | |
| Standard Features | Turnstile with electromagnetic lock linkage | Integrate the access gate and the electromagnetic lock to open the gate upon successful facial recognition. |
| Upload via network | In conjunction with the server-side software, it enables the uploading and aggregation of comparison data from multiple terminals. | |
| way to install | In-socket installation | |
