| Model Number: | JP2131A |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T |
Product Overview:
This 13-inch wall-mounted facial recognition password access control machine is an intelligent access control device that integrates advanced facial recognition technology and radio frequency identification technology. With its large-sized touch screen, high-definition camera, and powerful processing capabilities, it provides users with a secure and convenient solution for identity verification and access control.
Technical features:
1. Large-sized touch screen: Equipped with a 13.3-inch high-definition touch screen, providing an intuitive and convenient operation experience.
2. Facial recognition technology: Utilizes deep learning algorithms, supporting a 50,000-person face database, with a comparison time of ≤ 0.2 seconds, facial recognition distance of 0.3m - 1.5m, suitable for a height range of 1m - 2m, and facial verification accuracy rate of ≥ 99%.
3. Card swiping function: Supports various card types such as IC cards, ID cards, and CPU cards, enabling quick card swiping for access.
4. Multiple authentication methods: Supports separate facial recognition, separate card swiping, facial recognition + password, facial recognition + card swiping, and other authentication methods.
5. High-definition camera: Uses a 2-megapixel wide-angle wide dynamic camera, requiring no white light illuminator, and the facial recognition effect is not affected in dim or dark environments.
6. Remote management: Supports downloading or importing cards and face data through TCP/IP network platform or USB, enabling remote management.
Application advantages:
Enhance security: Through high-precision facial recognition and card swiping technology, it effectively prevents unauthorized access and enhances security.
Improve efficiency: The fast identity verification process reduces waiting time and improves access efficiency.
Easy management: Supports remote management and data export, facilitating personnel management and attendance statistics.
Application scenarios:
Enterprise office: Achieve quick attendance and access control for employees.
Residential communities: Enhance community security and control access by visitors.
Commercial buildings: Conduct personnel identity verification and access control in shopping malls, office buildings, etc.
Public transportation: Implement rapid security checks and identity verification at subway stations, train stations, etc.
This 13-inch wall-mounted facial recognition password access control machine, with its advanced technology, powerful functions, and flexible applications, provides users with an efficient and secure access control management solution.
| 13.3-Inch Video Intercom Facial Recognition Access Control Machine Parameters | ||
|
Basic Parameters |
Operating System | Android 11 system, also supports Ubuntu20.04, Debian10, Linux, Buildroot and Hongmeng system |
| Performance | RK3568, a quad-core Cortex-A55 architecture processor with a main frequency of up to 2.0MHz, a built-in convolutional neural network accelerator NPU, and supports 1T computing power | |
| Configuration | 2GB RAM + 16GB storage memory, LPDDR4 optional 4GB/8GB, EMMC supports up to 128GB | |
| LCD Screen Size | 13.3 inches | |
| Screen Resolution | 1920*1080 | |
| Brightness | 300cd/m², stable performance, service life of up to 60,000 hours, able to work 24/7 all year round | |
| Touchscreen | 10-point G+G capacitive touch screen, any point can withstand more than 50 million touches | |
| Camera | 2 million pixels, ultra-wide dynamic range, anti-backlight and strong light, selectable shooting focal length | |
| Speaker | Built-in 8Ω/3W*2 | |
| WIFI | High-performance WIFI, supports 802.11B/G/N | |
| Bluetooth | High-performance Bluetooth, supporting BT V5.2 | |
| Ethernet | 1 10/100/1000Mbps adaptive Ethernet | |
| Fill Light | White LED | |
| 4G | Optional | |
| Card Reader | Optional IC/ID/NFC/ID card reader, reading time <1S, card reading distance: 5-30MM | |
| Digital Keypad | 12-digit capacitive buttons | |
| Microphone | High-fidelity, noise-canceling microphone | |
| Working Parameters | Voltage 12V, current 3A; Operating temperature-25℃~+75℃; Humidity 5%~93%RH non-condensing | |
| External Interfaces | 2 USB, 1 RJ45, 1 DC, 1 headphone, 1 TF card slot, 1 SIM card slot, 1 HDMI, can be connected to 485/232/relay | |
| Face Algorithm |
Dynamic face detection and tracking based on video stream, 1:N recognition algorithm; Supports 50,000 face photo libraries and 1 million recognition records; When the face database is 50,000, the false recognition rate is 0.01% and the pass rate is 97%; |
|
| Materials | Surface Material | Mohs Level 7 Tempered glass explosion-proof and collision-proof; anti-scratch |
| Body Craftsmanship | Aluminum alloy CNC carved anodized frame + back shell sheet metal powder coating process | |
| Color | Black + Silver | |
| Standard Features | Turnstile-Electromagnetic Lock Linkage | Connect to the gate barrier and electromagnetic lock, and set it up to open the door after a successful verification |
| Network Upload | Cooperating with the server software, it can realize the upload and summary of comparison information of multiple terminals | |
| Installation | Wall-Mounted | |
![]()
![]()
![]()
|
