| Model Number: | JP21010A |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T |
Product Overview
In today's pursuit of maximizing space utilization and integrating equipment, the traditional wall-mounted access control terminals are no longer able to meet the strict requirements of high-end buildings for the integration of aesthetics and functionality. The 10.1-inch embedded facial recognition device has emerged - this is a multi-functional facial recognition access control terminal specifically designed for wall-mounted installation, integrating deep learning facial recognition. It is widely used in office lobbies, park entrances, campus access control, smart communities, etc., providing an "face recognition equals passage" seamless experience without any sensation of disturbance.
Core Value: Why choose embedded installation?
1. Integrated design, perfect integration of architectural aesthetics
Unlike the wall-mounted devices that protrude from the wall, the embedded devices adopt the method of pre-installed base box + panel installation. The device panel is flush with the wall, forming a seamless whole.
Enhance spatial style: No additional space occupation, avoiding the potential hazards of equipment protrusion
Suitable for various wall types: Supports pre-installed installation in new buildings and opening holes for renovation projects in old buildings
Higher security: Embedded installation is less likely to be forcibly disassembled, featuring IP65 dustproof and waterproof and IK08 explosion-proof grades, suitable for semi-outdoor and outdoor scenarios
2. 10.1-inch horizontal screen, better information display field of vision
Equipped with a 10.1-inch IPS high-definition touch screen with a resolution of 1280×800, the horizontal screen ratio is more in line with the installation habits of building access control scenarios, providing a wider field of vision when displaying personnel information, notice announcements, or advertising content. The screen brightness reaches up to 500 cd/m², remaining clear even in strong light.
3. Embedded operating system, stable and open
The device is equipped with an embedded Linux system, featuring low power consumption, fast startup, and strong anti-virus capabilities, ensuring stable operation 7×24 hours; or it can adopt the Android operating system, supporting open APIs and secondary development, facilitating integration with third-party management platforms.
Technical Architecture: Industrial-grade hardware, reliable and precise
Using a 2 million-pixel wide dynamic camera, it still maintains stable recognition in complex lighting environments such as backlight and low light.
High-performance processor and AI acceleration
Equipped with a high-performance processor (such as the AI chip of Hisilicon or the RK series chip), with NPU computing power, capable of ≤0.2-second rapid recognition under 50,000 face database, with an accuracy rate of over 99%.
Rich interfaces, seamless connection with access control system
Wiegand input/output (Wiegand 26/34): Compatible with mainstream access control controllers
RS485/RS232 serial ports: Expansion of ID card readers, QR code scanners, etc.
Relay output: Direct control of electric locks to open
| 10.1-Inch Embedded Touchscreen Face Recognition Device Parameters | ||
|
Basic Parameters |
Operating System | Android 11 system, also supports Ubuntu20.04, Debian10, Linux, Buildroot and Hongmeng system |
| Performance | RK3568, a quad-core Cortex-A55 architecture processor with a main frequency of up to 2.0MHz, a built-in convolutional neural network accelerator NPU, and supports 1T computing power | |
| Configuration | 2GB RAM + 16GB storage memory, LPDDR4 optional 4GB/8GB, EMMC supports up to 128GB | |
| LCD Screen Size | 10.1 inches | |
| Screen Resolution | 1280*800 | |
| Viewing Angle | IPS full viewing angle | |
| Brightness | 500cd/m², stable performance, service life of up to 60,000 hours, able to work 24/7 all year round | |
| Touchscreen | 10-point G+G capacitive touch screen, any point can withstand more than 50 million touches | |
| Camera | 2 million pixels, ultra-wide dynamic range, anti-backlight and strong light, selectable shooting focal length | |
| WIFI | High-performance WIFI, supports 802.11B/G/N | |
| Bluetooth | High-performance Bluetooth, supporting BT V5.2 | |
| Ethernet | 1 10/100/1000Mbps adaptive Ethernet | |
| 4G | Optional | |
| Speaker | Built-in 8Ω/3W | |
| 485 Output | Support | |
| Working Parameters | Voltage 12V; Current 3A; Operating temperature-25℃～+75℃; Humidity 5%~93%RH non-condensing | |
| External Interfaces | 2 USB, 1 RJ45, 1 DC, 1 headphone, 1 TF card slot, 1 SIM card slot, 1 HDMI, can be connected to 485/232/relay | |
| Face Algorithm |
Dynamic face detection and tracking based on video stream, 1:N recognition algorithm; Supports 50,000 face photo libraries and 1 million recognition records; When the face database is 50,000, the false recognition rate is 0.01% and the pass rate is 97%; |
|
|
Materials |
Surface Material | Mohs Level 7 Tempered glass explosion-proof and collision-proof, scratch-proof |
| Body Craftsmanship | Aluminum alloy CNC carved anodized frame + back shell sheet metal powder coating process | |
| Color | Black | |
| Standard Features | Turnstile-Electromagnetic Lock Linkage | Connect to the gate barrier and electromagnetic lock, and set it up to open the door after a successful verification |
| Network Upload | Cooperating with the server software, it can realize the upload and summary of comparison information of multiple terminals | |
| Installation | Embedded Installation | |
|
|
| Model Number: | JP21010A |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 10.1 inches |
| Payment Terms: | T/T |
Product Overview
In today's pursuit of maximizing space utilization and integrating equipment, the traditional wall-mounted access control terminals are no longer able to meet the strict requirements of high-end buildings for the integration of aesthetics and functionality. The 10.1-inch embedded facial recognition device has emerged - this is a multi-functional facial recognition access control terminal specifically designed for wall-mounted installation, integrating deep learning facial recognition. It is widely used in office lobbies, park entrances, campus access control, smart communities, etc., providing an "face recognition equals passage" seamless experience without any sensation of disturbance.
Core Value: Why choose embedded installation?
1. Integrated design, perfect integration of architectural aesthetics
Unlike the wall-mounted devices that protrude from the wall, the embedded devices adopt the method of pre-installed base box + panel installation. The device panel is flush with the wall, forming a seamless whole.
Enhance spatial style: No additional space occupation, avoiding the potential hazards of equipment protrusion
Suitable for various wall types: Supports pre-installed installation in new buildings and opening holes for renovation projects in old buildings
Higher security: Embedded installation is less likely to be forcibly disassembled, featuring IP65 dustproof and waterproof and IK08 explosion-proof grades, suitable for semi-outdoor and outdoor scenarios
2. 10.1-inch horizontal screen, better information display field of vision
Equipped with a 10.1-inch IPS high-definition touch screen with a resolution of 1280×800, the horizontal screen ratio is more in line with the installation habits of building access control scenarios, providing a wider field of vision when displaying personnel information, notice announcements, or advertising content. The screen brightness reaches up to 500 cd/m², remaining clear even in strong light.
3. Embedded operating system, stable and open
The device is equipped with an embedded Linux system, featuring low power consumption, fast startup, and strong anti-virus capabilities, ensuring stable operation 7×24 hours; or it can adopt the Android operating system, supporting open APIs and secondary development, facilitating integration with third-party management platforms.
Technical Architecture: Industrial-grade hardware, reliable and precise
Using a 2 million-pixel wide dynamic camera, it still maintains stable recognition in complex lighting environments such as backlight and low light.
High-performance processor and AI acceleration
Equipped with a high-performance processor (such as the AI chip of Hisilicon or the RK series chip), with NPU computing power, capable of ≤0.2-second rapid recognition under 50,000 face database, with an accuracy rate of over 99%.
Rich interfaces, seamless connection with access control system
Wiegand input/output (Wiegand 26/34): Compatible with mainstream access control controllers
RS485/RS232 serial ports: Expansion of ID card readers, QR code scanners, etc.
Relay output: Direct control of electric locks to open
| 10.1-Inch Embedded Touchscreen Face Recognition Device Parameters | ||
|
Basic Parameters |
Operating System | Android 11 system, also supports Ubuntu20.04, Debian10, Linux, Buildroot and Hongmeng system |
| Performance | RK3568, a quad-core Cortex-A55 architecture processor with a main frequency of up to 2.0MHz, a built-in convolutional neural network accelerator NPU, and supports 1T computing power | |
| Configuration | 2GB RAM + 16GB storage memory, LPDDR4 optional 4GB/8GB, EMMC supports up to 128GB | |
| LCD Screen Size | 10.1 inches | |
| Screen Resolution | 1280*800 | |
| Viewing Angle | IPS full viewing angle | |
| Brightness | 500cd/m², stable performance, service life of up to 60,000 hours, able to work 24/7 all year round | |
| Touchscreen | 10-point G+G capacitive touch screen, any point can withstand more than 50 million touches | |
| Camera | 2 million pixels, ultra-wide dynamic range, anti-backlight and strong light, selectable shooting focal length | |
| WIFI | High-performance WIFI, supports 802.11B/G/N | |
| Bluetooth | High-performance Bluetooth, supporting BT V5.2 | |
| Ethernet | 1 10/100/1000Mbps adaptive Ethernet | |
| 4G | Optional | |
| Speaker | Built-in 8Ω/3W | |
| 485 Output | Support | |
| Working Parameters | Voltage 12V; Current 3A; Operating temperature-25℃～+75℃; Humidity 5%~93%RH non-condensing | |
| External Interfaces | 2 USB, 1 RJ45, 1 DC, 1 headphone, 1 TF card slot, 1 SIM card slot, 1 HDMI, can be connected to 485/232/relay | |
| Face Algorithm |
Dynamic face detection and tracking based on video stream, 1:N recognition algorithm; Supports 50,000 face photo libraries and 1 million recognition records; When the face database is 50,000, the false recognition rate is 0.01% and the pass rate is 97%; |
|
|
Materials |
Surface Material | Mohs Level 7 Tempered glass explosion-proof and collision-proof, scratch-proof |
| Body Craftsmanship | Aluminum alloy CNC carved anodized frame + back shell sheet metal powder coating process | |
| Color | Black | |
| Standard Features | Turnstile-Electromagnetic Lock Linkage | Connect to the gate barrier and electromagnetic lock, and set it up to open the door after a successful verification |
| Network Upload | Cooperating with the server software, it can realize the upload and summary of comparison information of multiple terminals | |
| Installation | Embedded Installation | |
