| Model Number: | JP2151A |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T |
Product Overview:
This 15.6-inch wall-mounted Android system facial recognition smart display is an intelligent display device that integrates facial recognition technology. It is equipped with the Android 11 operating system, providing a wide range of functions and high degree of customizability, suitable for various occasions such as enterprises, schools, hospitals, etc.
Technical Features:
1. Operating System: Built-in Android 11 operating system, ensuring smooth device operation and strong compatibility.
2. Display Screen: Equipped with a 15.6-inch full HD LED backlit display, with a resolution of 1920×1080, providing a clear visual experience.
3. Facial Recognition Technology: Built-in facial algorithm, supporting face comparison, with fast recognition speed and high accuracy.
4. Camera Parameters: 200-megapixel dual-camera.
5. Communication Methods: Supports TCP/IP, WiFi, and other communication methods.
6. Hardware Interfaces: Includes RJ45, RS485, RS232, USB interfaces and other interfaces.
7. Authentication Methods: Supports face recognition, with a 50,000-person face database.
8. Touch Control Parameters: Capacitive touch control, ten-point touch control.
Application Advantages:
Enhanced Security: Through facial recognition technology, effectively enhance the security of identity verification.
Improved Efficiency: Fast recognition speed and high accuracy of recognition effectively improve work efficiency.
| 15.6-Inch Digital Doorplate Display Screen Parameters | ||
|
Basic Parameters |
Operating System | Android 8.0 system |
| Performance | RK3288 main frequency up to 1.8 GHZ | |
| Configuration | 2GB RAM + 16GB storage memory | |
| LCD Screen Size | 15.6 inches | |
| Screen Resolution | 1920*1080 | |
| Brightness | 300cd/m², stable performance, service life of up toMore than 60,000 hours, able to work 24/7 all year round | |
| Touchscreen | 10-point G+G capacitive touch screen, any point can withstand more than 50 million touches | |
| Camera | 2 million pixels, ultra-wide dynamic range, anti-backlight and strong light, selectable shooting focal length | |
| PoE Power Supply | Support | |
| Speaker | Built-in 8Ω/3W*2 | |
| Working Parameters | Voltage 12V, current 3A, operating temperature-25℃～+75℃, humidity 5%~93%RH non-condensing | |
| Three-Color Indicator Light | Red, blue, green | |
| External Interfaces | 2 USB ports, 1 RJ45 port, 1 DC port, 1 TF card slot, 1 SIM card slot, 1 HDMI, external 485/232/relay | |
| Face Algorithm |
Dynamic face detection and tracking based on video stream, 1:N recognition algorithm; Supports 50,000 face photo libraries and 1 million recognition records; When the face database is 50,000, the false recognition rate is 0.01% and the pass rate is 97%; |
|
| Materials | Surface Material | Mohs Level 7 Tempered glass explosion-proof and collision-proof, anti-scratch |
| Body Craftsmanship | Aluminum alloy CNC carved anodized frame + back shell sheet metal powder coating process | |
| Color | Black + Silver | |
| Standard Features | Turnstile-Electromagnetic Lock Linkage | Connect to the gate barrier and electromagnetic lock, and set it up to open the door after a successful facial comparison |
| Network Upload | Cooperating with the server software, it can realize the upload and summary of comparison information of multiple terminals | |
| Installation | Wall-Mounted | |
|
|
| Model Number: | JP2151A |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 384.16 × 233.5 × (13 + 29) mm |
| Payment Terms: | T/T |
Product Overview:
This 15.6-inch wall-mounted Android system facial recognition smart display is an intelligent display device that integrates facial recognition technology. It is equipped with the Android 11 operating system, providing a wide range of functions and high degree of customizability, suitable for various occasions such as enterprises, schools, hospitals, etc.
Technical Features:
1. Operating System: Built-in Android 11 operating system, ensuring smooth device operation and strong compatibility.
2. Display Screen: Equipped with a 15.6-inch full HD LED backlit display, with a resolution of 1920×1080, providing a clear visual experience.
3. Facial Recognition Technology: Built-in facial algorithm, supporting face comparison, with fast recognition speed and high accuracy.
4. Camera Parameters: 200-megapixel dual-camera.
5. Communication Methods: Supports TCP/IP, WiFi, and other communication methods.
6. Hardware Interfaces: Includes RJ45, RS485, RS232, USB interfaces and other interfaces.
7. Authentication Methods: Supports face recognition, with a 50,000-person face database.
8. Touch Control Parameters: Capacitive touch control, ten-point touch control.
Application Advantages:
Enhanced Security: Through facial recognition technology, effectively enhance the security of identity verification.
Improved Efficiency: Fast recognition speed and high accuracy of recognition effectively improve work efficiency.
| 15.6-Inch Digital Doorplate Display Screen Parameters | ||
|
Basic Parameters |
Operating System | Android 8.0 system |
| Performance | RK3288 main frequency up to 1.8 GHZ | |
| Configuration | 2GB RAM + 16GB storage memory | |
| LCD Screen Size | 15.6 inches | |
| Screen Resolution | 1920*1080 | |
| Brightness | 300cd/m², stable performance, service life of up toMore than 60,000 hours, able to work 24/7 all year round | |
| Touchscreen | 10-point G+G capacitive touch screen, any point can withstand more than 50 million touches | |
| Camera | 2 million pixels, ultra-wide dynamic range, anti-backlight and strong light, selectable shooting focal length | |
| PoE Power Supply | Support | |
| Speaker | Built-in 8Ω/3W*2 | |
| Working Parameters | Voltage 12V, current 3A, operating temperature-25℃～+75℃, humidity 5%~93%RH non-condensing | |
| Three-Color Indicator Light | Red, blue, green | |
| External Interfaces | 2 USB ports, 1 RJ45 port, 1 DC port, 1 TF card slot, 1 SIM card slot, 1 HDMI, external 485/232/relay | |
| Face Algorithm |
Dynamic face detection and tracking based on video stream, 1:N recognition algorithm; Supports 50,000 face photo libraries and 1 million recognition records; When the face database is 50,000, the false recognition rate is 0.01% and the pass rate is 97%; |
|
| Materials | Surface Material | Mohs Level 7 Tempered glass explosion-proof and collision-proof, anti-scratch |
| Body Craftsmanship | Aluminum alloy CNC carved anodized frame + back shell sheet metal powder coating process | |
| Color | Black + Silver | |
| Standard Features | Turnstile-Electromagnetic Lock Linkage | Connect to the gate barrier and electromagnetic lock, and set it up to open the door after a successful facial comparison |
| Network Upload | Cooperating with the server software, it can realize the upload and summary of comparison information of multiple terminals | |
| Installation | Wall-Mounted | |
