| Model Number: | 002 |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T |
Core functions and highlights:
1. Dual verification with face and fingerprint, strictly preventing proxy
The device supports both dynamic face recognition and capacitive fingerprint recognition, and allows for flexible combination of verification methods (such as "face + fingerprint" dual verification), significantly enhancing the security of access control. Combined with dual-eye live detection cameras, it can effectively defend against forged attacks such as photos and videos.
2. Ultra-fast recognition, efficient passage
Equipped with a high-performance processor, the face recognition speed is less than 0.2-0.3 seconds, and the fingerprint recognition also responds in milliseconds. Combined with a 2-megapixel wide dynamic camera, it can stably recognize in strong light, backlight or dim light environments.
3. 5-inch vertical screen interaction, wall-mounted installation
The 5-inch IPS high-definition touch screen provides a clear interaction interface. Adopting a wall-mounted design, it comes with standard wall installation components, suitable for indoor and semi-outdoor wall installation.
4. Integrated attendance and access control management
The device supports local offline operation, with a standard capacity of 5,000 faces, 5,000 fingerprints and 500,000 records (some models support expansion to tens of thousands of people). It has complete access control functions (time period control, combined opening, fire linkage, etc.), and supports offline shift scheduling and USB export of reports. After connecting to the network, data synchronization and remote management can be achieved through TCP/IP or Wi-Fi.
Applicable scenarios
Enterprise/Office Building: Prevent fake clock-in, precise attendance and access control management.
Factory/Park: High-security access control at entrances and exits.
Government/Institutional Organization: Office areas with strict requirements for identity verification.
| Face Recognition Attendance Access Control Machine Parameters | ||
|
Basic Parameters |
Operating System | Android 11 system, also supports Ubuntu20.04, Debian10, Linux, Buildroot and Hongmeng system |
| Performance | RK3568, a quad-core Cortex-A55 architecture processor with a main frequency of up to 2.0MHz, a built-in convolutional neural network accelerator NPU, and supports 1T computing power | |
| Configuration | 2GB RAM + 16GB storage memory, LPDDR4 optional 4GB/8GB, EMMC supports up to 128GB | |
| LCD Screen Size | 8 inches | |
| Screen Resolution | 800*1280 | |
| Viewing Angle | IPS full viewing angle | |
| Brightness | 500cd/m², stable performance, service life of more than 60,000 hours, able to work 24/7 all year round | |
| Touchscreen | 10-point G+G capacitive touch screen, any point can withstand more than 50 million touches | |
| Camera | Binocular: visible light + infrared light, 2 million pixels, ultra-wide dynamic range, support for liveness detection, anti-backlight and strong light, selectable shooting focal length | |
| Speaker | Built-in 8Ω/3W | |
| WIFI | High-performance WIFI, supports 802.11B/G/N | |
| Bluetooth | High-performance Bluetooth, supporting BT V5.2 | |
| Ethernet | 1 10/100/1000Mbps adaptive Ethernet | |
| Three-Color Indicator Light | Red, white, green | |
| Microphone | Optional | |
| 4G | Optional | |
| Working Parameters | Voltage 12V; Current 3A; Operating temperature-25℃～+75℃; Humidity 5%~93%RH non-condensing | |
| External Interfaces | 1 USB/OTG, 1 RJ45 standard interface, 1 relay output, 1 DC power supply, 1 Wiegand, 1 232/485 | |
| Face Algorithm |
Dynamic face detection and tracking based on video stream, 1:N recognition algorithm; Dynamic dual-camera anti-counterfeiting completely solves the problem of photo and video fraud on various media; Supports 50,000 face photo libraries and 1 million recognition records; When the face database is 50,000, the false recognition rate is 0.01% and the pass rate is 97%; |
|
|
Materials |
Surface Material | Mohs Level 7 Tempered glass explosion-proof and collision-proof, anti-scratch |
| Body Craftsmanship | CNC-machined aluminum alloy with anodized finish | |
| Color | Black + Silver | |
| Standard Features | Turnstile-Electromagnetic Lock Linkage | Connect to the gate barrier and electromagnetic lock, and set it up to open the door after a successful facial comparison |
| Network Upload | Cooperating with the server software, it can realize the upload and summary of comparison information of multiple terminals | |
| Installation | Wall-Mounted | |
|
|
| Model Number: | 002 |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | 5 inches |
| Payment Terms: | T/T |
Core functions and highlights:
1. Dual verification with face and fingerprint, strictly preventing proxy
The device supports both dynamic face recognition and capacitive fingerprint recognition, and allows for flexible combination of verification methods (such as "face + fingerprint" dual verification), significantly enhancing the security of access control. Combined with dual-eye live detection cameras, it can effectively defend against forged attacks such as photos and videos.
2. Ultra-fast recognition, efficient passage
Equipped with a high-performance processor, the face recognition speed is less than 0.2-0.3 seconds, and the fingerprint recognition also responds in milliseconds. Combined with a 2-megapixel wide dynamic camera, it can stably recognize in strong light, backlight or dim light environments.
3. 5-inch vertical screen interaction, wall-mounted installation
The 5-inch IPS high-definition touch screen provides a clear interaction interface. Adopting a wall-mounted design, it comes with standard wall installation components, suitable for indoor and semi-outdoor wall installation.
4. Integrated attendance and access control management
The device supports local offline operation, with a standard capacity of 5,000 faces, 5,000 fingerprints and 500,000 records (some models support expansion to tens of thousands of people). It has complete access control functions (time period control, combined opening, fire linkage, etc.), and supports offline shift scheduling and USB export of reports. After connecting to the network, data synchronization and remote management can be achieved through TCP/IP or Wi-Fi.
Applicable scenarios
Enterprise/Office Building: Prevent fake clock-in, precise attendance and access control management.
Factory/Park: High-security access control at entrances and exits.
Government/Institutional Organization: Office areas with strict requirements for identity verification.
| Face Recognition Attendance Access Control Machine Parameters | ||
|
Basic Parameters |
Operating System | Android 11 system, also supports Ubuntu20.04, Debian10, Linux, Buildroot and Hongmeng system |
| Performance | RK3568, a quad-core Cortex-A55 architecture processor with a main frequency of up to 2.0MHz, a built-in convolutional neural network accelerator NPU, and supports 1T computing power | |
| Configuration | 2GB RAM + 16GB storage memory, LPDDR4 optional 4GB/8GB, EMMC supports up to 128GB | |
| LCD Screen Size | 8 inches | |
| Screen Resolution | 800*1280 | |
| Viewing Angle | IPS full viewing angle | |
| Brightness | 500cd/m², stable performance, service life of more than 60,000 hours, able to work 24/7 all year round | |
| Touchscreen | 10-point G+G capacitive touch screen, any point can withstand more than 50 million touches | |
| Camera | Binocular: visible light + infrared light, 2 million pixels, ultra-wide dynamic range, support for liveness detection, anti-backlight and strong light, selectable shooting focal length | |
| Speaker | Built-in 8Ω/3W | |
| WIFI | High-performance WIFI, supports 802.11B/G/N | |
| Bluetooth | High-performance Bluetooth, supporting BT V5.2 | |
| Ethernet | 1 10/100/1000Mbps adaptive Ethernet | |
| Three-Color Indicator Light | Red, white, green | |
| Microphone | Optional | |
| 4G | Optional | |
| Working Parameters | Voltage 12V; Current 3A; Operating temperature-25℃～+75℃; Humidity 5%~93%RH non-condensing | |
| External Interfaces | 1 USB/OTG, 1 RJ45 standard interface, 1 relay output, 1 DC power supply, 1 Wiegand, 1 232/485 | |
| Face Algorithm |
Dynamic face detection and tracking based on video stream, 1:N recognition algorithm; Dynamic dual-camera anti-counterfeiting completely solves the problem of photo and video fraud on various media; Supports 50,000 face photo libraries and 1 million recognition records; When the face database is 50,000, the false recognition rate is 0.01% and the pass rate is 97%; |
|
|
Materials |
Surface Material | Mohs Level 7 Tempered glass explosion-proof and collision-proof, anti-scratch |
| Body Craftsmanship | CNC-machined aluminum alloy with anodized finish | |
| Color | Black + Silver | |
| Standard Features | Turnstile-Electromagnetic Lock Linkage | Connect to the gate barrier and electromagnetic lock, and set it up to open the door after a successful facial comparison |
| Network Upload | Cooperating with the server software, it can realize the upload and summary of comparison information of multiple terminals | |
| Installation | Wall-Mounted | |
